Rapiscan Eagle® G45

The Rapiscan Eagle® G45 is a rail mounted gantry inspection system which offers a 4.5 MeV high-energy X-ray Imaging system. It is well-suited for cargo screening at entrances to critical facilities, as well as border crossings and seaports.

The Rapiscan Eagle® G45 4.5 MeV X-ray imaging system easily penetrates light, medium and dense cargo, for the identification of contraband, such as explosives, weapons and narcotics.

With best-in-class imaging, robust standard features and advanced options, the Rapiscan Eagle® G45 offers a highly-automated system for automated, reliable inspection.

• The Eagle® G45 is a 4.5 MeV X-ray imaging system that enables inspection of light, medium and dense cargo, verification of manifests and identification of contraband, such as explosives, weapons and narcotics.
• The Eagle® G45 is consists of the gantry, which supports the X-ray generator and detector array, the rails and the containerised offices.
• Rapiscan Eagle® Gantry cargo and vehicle scanners deliver high quality X-ray imaging in a highly-automated scanning operation. In drive-by scan mode, unoccupied vehicles parked between the rails are scanned as the gantry moves past them.
• Multiple scanning modes. When high throughput is needed, the Eagle Gantry® can be operated in the optional drive-through portal scan mode which automatically scans the cargo as trucks drive through the stationary gantry.

• With the optional CabScan™ mode; a low energy, low dose X-ray source is used to scan the drivers cab, switching automatically to a high energy source after the cab area has moved through the portal, with the resulting X-ray images sent to a nearby inspection office or containerised office facility for review and evaluation
• Radiation shielding walls or a weatherproof building can be optionally added.

Rapiscan Eagle® G45 Standard Features

• Rail mounted gantry scanner
• Scan unoccupied objects parked between the rails
• Highly automated scanning operation
• 4.5 MeV X-ray imaging system
• Industry leading X-ray imaging quality
• Easy-to-use Rapiscan Cargo Viewer software
• Meets radiation safety standards
• Designed for easy relocation
• Easy to maintain

Various Optional features are available for system and operational enhancement
